2x2 LED Troffer Light (4Pack) 20W-40W Adjustable 3k/3.5k/4k/5k/6.5k (5CCT)
Choose options
Description
- 2x2 LED center basket Troffer light, wattage and CCT adjustable, 120-277V.
- LED Troffer light is used in any indoor locations with T-bar ceilings such as shopping malls, offices, schools, hospitals, etc. It is used to replace the big whole fluorescent fixture that usually has 2-4 tube lights inside. Using our LED Troffer light, you won’t need the old, big, and expensive fluorescent fixtures without needing to buy the tube lights separately either you are replacing the old fixtures or using it for the new construction.
- Available in size 2X4, 2x2, our LED center basket Troffer light (2x4 and 2x2 led light) are wattage and CCT adjustable, suitable for any requirements and applications.
Feature
- Wattage and CCT adjustable: Our Troffer lights are 5 wattage and 5 CCT adjustable, meeting the needs of any applications or settings.
- Easy Installation: LED Troffer lights are light weight, making installation easy and hassle free.
- Dimmable: On top of wattage and CCT adjustable features, our Troffer lights are also 0-10V dimmable.
- 5-Year Warranty: We offer a comprehensive 5-year warranty, ensuring long-lasting performance and peace of mind.
- Energy Efficient: Our LED Troffer lights use significantly less energy compared to traditional lighting, reducing your electricity bills. We will demonstrate how much energy will be saved using our troffer lights using the graphs below.
- High Lumen Output: Because of its energy efficiency, the LED Troffer light has high lumen output even set at a small wattage
- Long Lifespan: With a lifespan of 50,000 hours, our LED Troffer lights last significantly longer than traditional fixtures.
- Eco-Friendly: Eco-Friendly: Unlike fluorescent and compact lights (CFLs), LED lights do not contain mercury, harmful gases or other hazardous materials, making them safer for the environment and easier to dispose. The combined effect of lower energy consumption and longer lifespan means LEDs have a smaller carbon footprint over their lifecycle compared to other lighting types.
Specification
| Wattage | 20W/25W/30W/35W/40W adjustable | Voltage: | 120-277V |
|---|---|---|---|
| Cover | Lens | Certificate | ETL&DLC |
| CCT |
3000k/3500k4000k/ 5000k/6500k |
Lifespan | 50,000 hours |
| Lumen/W | 125lm/W | CRI | >80 |
| Carton size | 24.8X 24.8X 9.8 inches | Dimmable | Yes |
| Carton weight | 19.8 lb | Warranty | 5-year |
LED Energy consumption comparison
| LED Troffer light | Wattage | Fluorescent fixture | Wattage |
|---|---|---|---|
| 2x4 LED Troffer | 30W-72W | 2x4 fluorescent | 96W-128W + Ballast wattage |
| 2x2 LED Troffer | 20W-40W | 2x2 fluorescent | 36W-72W+ ballast wattage |
Best LED Troffer Lights 2x2: Features, Benefits, and Applications
LED Troffer Lights 2x2 are a revolutionary lighting solution designed to replace traditional fluorescent fixtures in commercial and office settings. With their energy-efficient LED technology, they provide superior illumination while reducing energy consumption and maintenance costs. Their sleek, low-profile design makes them an excellent choice for spaces where aesthetics and functionality are equally important. This article explores the structure, working principle, application scope, and ideal work environment for LED Troffer Lights 2x2, helping you understand why they are a preferred lighting option for modern interiors.
What Are LED Troffer Lights 2x2?
LED Troffer Lights 2x2 are modern lighting fixtures designed to replace traditional fluorescent troffers commonly found in commercial and office spaces. These lights are named for their size, measuring 2 feet by 2 feet, and are typically installed in drop ceilings. They utilize energy-efficient LED technology, offering brighter illumination, longer lifespans, and lower energy consumption compared to older lighting systems. LED Troffer Lights 2x2 are known for their sleek, low-profile design, making them a popular choice for environments where aesthetics and functionality are equally important.
LED Troffer Lights 2x2 Structure and Components
LED Troffer Lights 2x2 are composed of several key components that work together to deliver efficient and reliable lighting:
LED Chips: The core light source, providing high lumens with minimal energy usage.
Driver: Regulates the power supply to ensure consistent performance and protect the LEDs from voltage fluctuations.
Housing: Typically made of aluminum or steel, the housing provides durability and aids in heat dissipation.
Diffuser: A cover that evenly distributes light and reduces glare, often made of acrylic or polycarbonate.
Mounting Frame: Allows for easy installation in drop ceilings or suspended grids.
These components are engineered to ensure optimal performance, longevity, and ease of maintenance.
How Do LED Troffer Lights 2x2 Work?
LED Troffer Lights 2x2 operate through a combination of advanced electrical and optical engineering. Here’s a step-by-step breakdown of how they function:
1. Power Supply: The fixture is connected to an electrical source, which powers the internal driver.
2. Driver Regulation: The driver converts incoming AC power to the appropriate DC voltage required by the LED chips.
3. Light Emission: The LED chips emit light when electrical current passes through them, producing bright, consistent illumination.
4. Heat Management: The housing and heat sink dissipate excess heat, ensuring the LEDs operate at optimal temperatures.
5. Light Distribution: The diffuser spreads the light evenly across the area, minimizing shadows and glare.
This efficient process ensures that LED Troffer Lights 2x2 deliver high-quality lighting while consuming significantly less energy than traditional options.
Application Scope of LED Troffer Lights 2x2
LED Troffer Lights 2x2 are versatile and suitable for a wide range of applications, including:
Office Spaces: Provides bright, uniform lighting that enhances productivity and reduces eye strain.
Educational Institutions: Ideal for classrooms, libraries, and hallways due to their energy efficiency and long lifespan.
Healthcare Facilities: Offers clean, flicker-free lighting that meets the stringent requirements of hospitals and clinics.
Retail Stores: Enhances product visibility and creates an inviting atmosphere for customers.
Industrial Settings: Withstands harsh environments while delivering reliable illumination.
Their adaptability makes them a go-to lighting solution for both commercial and institutional settings.
Optimal Work Environment for LED Troffer Lights 2x2
To maximize the performance and lifespan of LED Troffer Lights 2x2, it’s important to install them in environments that meet the following conditions:
Temperature: LED troffers perform best in environments with temperatures between -20°C and 40°C (-4°F to 104°F).
Humidity: Low to moderate humidity levels are ideal to prevent moisture damage.
Ceiling Type: Designed for drop ceilings but can be adapted for other ceiling types with proper mounting hardware.
Voltage Stability: Ensure a stable power supply to avoid fluctuations that could affect the driver’s performance.
By adhering to these conditions, you can ensure that your LED Troffer Lights 2x2 operate efficiently and last for their intended lifespan.
LED Troffer Lights 2x2 offer a cost-effective and high-performance lighting solution for various commercial and institutional applications. Their advanced components, including high-lumen LED chips, efficient drivers, and durable housings, ensure long-lasting performance and minimal maintenance. By operating within the recommended temperature, humidity, and voltage conditions, these lights provide optimal efficiency and durability. Whether for offices, classrooms, healthcare facilities, or retail spaces, LED Troffer Lights 2x2 deliver uniform, glare-free illumination that enhances productivity and comfort. Investing in these modern lighting fixtures can significantly improve energy efficiency and overall lighting quality.
